Ble to Wifi IoT Gateway iBeacon Reader HTTP and MQTT Supported for Indoor Location

$60.00

Minew IoT gateway is used for beacon data management, it collects the data from iBeacon, Eddystone, sensors and other ble devices, and then sends to the local server or remote cloud. It common used for application like indoor location, asset tracking, people tracking etc.

Ble to Wifi IoT Gateway iBeacon Reader HTTP and MQTT Supported for Indoor Location

G1 is a Bluetooth low energy (BLE) to Wi-Fi connectivity gateway without the uses of smartphones or apps. The G1 gateway collects the data from iBeacon, Eddystone, BLE sensor and other BLE devices, and then sends to the local server or remote cloud server by HTTP / MQTT protocol over Wi-Fi / Ethernet. The subsequent version G1 Gateway will also implement the connection with BLE devices. This product is a science fiction with a color lamp ring on the top. It can be fixed by sticker or screw thread.

General Features:

  • Supports input with DC 5.0V, 1A, micro-USB
  • Supports 10/100 Ethernet with 802.3af PoE
  • Supports firmware upgrade Over-the-Air
  • Supports HTTP(support SSL/TLS)/MQTT(support SSL/TLS)
  • Operating temperature: -25℃ to 65℃

WIFI:

  • Wifi module based on the Mediatek’s MT7628/MT7688 575MHz 32-bit Application Processor
  • 1T1R/2T2R 2.4 GHz with 150/300 Mbps PHY data rate,802.11b/g/n WiFi
  • Two USB 2.0 Host Connectors and one TF Card slot
  • 128 Mbyte 16-bit DDR2 RAM
  • 16 Mbyte SPI NOR Flash
  • RGB LED strip as the status indicator
  • OpenWrt, Linux distribution for embedded devices.

BLE:

  • BLE module based on the Nordic’s nRF52832 with ARM® Cortex®-M4 64MHz 32-bit processor
  • BLE module have built-in power amplifier chip,make scanning BLE more sensitive
  • At least Bluetooth 4.0(Only Bluetooth Low Energy)

Application:

  • iBeacon / Eddystone / other BLE tag receiver
  • BLE sensor reader / receiver
  • Asset tracking
  • Access control management
  • Advertisement promotion
  • Indoor location and position
  • Industrial automation
