Bluetooth Audio Amplifier Board with 2 x 100W + 200W 2.1 Channels – TSA7500B (Apt-X)

$59.50

TSA7500 2x100W + 220W 2.1 channels audio amplifier board with AudioB pro Bluetooth module that supports Apt-X. It has perfect class-D architecture(Based on TPA3221), two channels have 100W power output, and another channel has 200W power output. All the channels are capable of outputting nominal power simultaneously and continuously. Any DC12V-30V power supply can power this board. You can use it to drive any 4Ω or 8Ω passive speakers. TSA7500 can also be connected with our  TSA1000, TSA1010, or TSA1020 external audio volume control board. People can adjust the audio volume by rotating the actual knob. You can connect this DSP board to the TSA1701 Audio DSP Board and adjust the subwoofer audio tones.

Bluetooth Audio Amplifier Board with 2 x 100W + 200W 2.1 Channels – TSA7500B (Apt-X)

It’s a 2.1 channels amplifier board. That channel for the subwoofer is 200W mono output. You can pair it with a mobile phone or a computer etc. Power the amplifier board. Use your phone or PC (etc.) to search for a new Bluetooth device. The module will appear as “TSA7500”. You don’t need a PIN, pair it, and then you can play music. The highlight point is that Apt-X and TWS supported. Therefore, Users can stream audio to 2 pair amplifier boards simultaneously wirelessly.

  • TSA7500 can auto-detect the Aux in/Line in Audio input. Bluetooth Audio source has a higher priority. When Bluetooth audio is paused, or Bluetooth is disconnected. The Amplifier will output the Aux in/Line in audio.
  • An audio connector can connect with an external DSP to set the subwoofer audio tones.
  • BVC Port: BVC port can be connected with our Audio volume controller to control the Bluetooth audio volume.


TSA7500 can auto-detect the Aux in/Line in Audio input. Bluetooth Audio source has a higher priority. When Bluetooth audio is paused, or Bluetooth is disconnected. The Amplifier will output the Aux in/Line in audio.

TSA7500 + TSA1000, Both Aux-in and Bluetooth audio volume can be controlled through the BVC port

Two boards work in TWS mode

*User must remove the slave board Aux in Enable jumper before pairing two boards

  • S1 – Long press 3s into pairing mode. Long press 6s clear the pairing info.
  • S1+S2 – Long press 1s into TWS slave mode.
  • S1+S3 – Long press 1s into TWS master mode.
  • S2+S3 – Long press 1s disconnect TWS connection.

Features:

  • Size: 15cm x 9cm x 2.5cm
  • aptX, aptX Low Latency, SBC and AAC
  • Bluetooth 4.2
  • Bluetooth audio volume control port(BVC)
  • Aux in/Line in auto-detect
  • 2.1 channels
  • Working voltage: DC12V-30V
  • Over/under voltage protection
  • Over-current protection
  • Over-temperature protection

Applications:

  • Personal computer
  • Background music system
  • Musical instrument amplifiers
  • Home DIY
  • Car Audio

Documents:

  • How to change the BT name
  • How to enable BT password
  • How to change Bluetooth audio gains
  • TSA7500B Bluetooth module PSR file

Reviews

There are no reviews yet.

Be the first to review “Bluetooth Audio Amplifier Board with 2 x 100W + 200W 2.1 Channels – TSA7500B (Apt-X)”

Product Manuals

If applicable, the Product Documentation, Brochure, Reference Materials, CAD design(s),.STEP file(s) and other drawing files, Manuals, and Tutorials will be available for download upon purchase. In addition, the order confirmation email will include a downloadable link to the product file(s), which can also be downloaded from the My Account section if needed.


Founded in 2009, TinySine Electronics is a smart home and open source hardware provider, catering to hardware engineers, DIY enthusiasts and interactive designers. Our ever-growing product catalog includes over 700 components and widgets from sensors, robotic platforms, communication modules to smart home relay boards.

Shipping Policy

WE SHIP WORLDWIDE: We primarily ship via FedEx, UPS, DHL, EMS, TNT, and USPS because they are fast, reliable, and easily trackable. We usually ship within two to three business days after the full payment. Standard delivery generally occurs within 5 to 7 business days after the shipping date. However, sometimes delivery may take about 7 to 10 business days, depending on the shipping destination, logistics mode, weather conditions, product weight, size, or shipping company distribution structures based on re-planning, such as staff shortages caused by COVID.

SHIPPING COSTS: For some industrial products, e.g., heavy wheels, CNC machines, etc., the shipping cost is calculated based on the product weight, not quantity. To benefit from lower shipping costs for orders with multiple items, don't hesitate to contact us at sales@ozrobotics.com. Our shipping rates are listed very clearly on each product page under the SHIPPING tab. Additionally, to see the shipping cost for your country, add the item to the Shopping Cart; you will see the shipping cost based on your Country and Location.

CUSTOMS and TARIFFS: While not all products require a tariff, some products may require a minimal tariff if applicable in your country for orders of $800.00 and above. The total amount for your order does not include a customs fee/tariff. A tariff belongs to the buyer when applicable. Why don't we add tariffs to the product's retail price? - If all countries deducted the same tariff amount, we would have added the tariff amount to the product price. However, we do not do that because each country charges a different amount, while some do not even charge. Therefore we can't add any tariff to the product's retail pricing. Oz Robotics, Manufacturing Partner, or Supplier are not responsible for tariffs. Please check the "Made In" and "Made By" labels on the product page to see the product's origin. The total amount for your order does not include any duties, import taxes, customs fees, and GST/VAT. The buyer must pay all import duties. Please click here to see more on Tariffs.

Return Policy

COVID: We are suspending product returns due to the current COVID-19 pandemic unless there is a manufacturing defect. Please study the product and ask us questions before you buy. Thank you.

ORDER CANCELLATION: After you place an order, you have 5 hours to request an order cancellation. After 5 hours, your item(s) have either already been shipped, prepared to ship, or are currently being custom-made. It means we will not process your cancellation request after this period has passed. By placing your order, you signify that you agree to be bound by our Order Cancellation Policy.

PAYPAL and STRIPE SERVICE FEES: Please note both PayPal and Stripe do not offer a refund for the service fees they charge when you purchase a product. Therefore, after placing an order, if you change your mind and ask for a refund, we will deduct the service fee for PayPal or Stripe, whichever one you used to purchase. If you have any questions about this, please contact PayPal or Stripe.

EXCHANGE POLICY: Oz Robotics wants you to be happy with your new purchase. However, we abide by the exchange policy of our suppliers because we do not manufacture these products; our suppliers do. Once you used the product, our supplier(s) and we have the right not to issue a refund. Still, we will offer an exchange for the wrongly purchased items or products with serious and irreversible defects or technical problem(s). The buyer will pay the shipping fee for wrongly purchased products or any other similar issues. If the product you purchased is defective, please email us at support@ozrobotics.com with some photos or a video of the defective parts to evaluate before you send it. Click HERE for more on Refund and Replacement Policy

REFUND POLICY: Oz Robotics accepts refunds on a minimal basis unless there is a manufacturing defect. For any electronic items, returns are only accepted on devices with serious and irreversible problems; meanwhile, the customer must apply for the returns within seven days from the delivery date. Before a refund acceptance, please include images or a video and any other material proof of the defect. However, we abide by the exchange policy of our suppliers because we do not manufacture these products; our suppliers do. For more info on Refund and Replacement Policy please visit Refund and Replacement Policy.

Other than our supplier’s default policy, once a return is agreed upon, you can ship your defective item to the provided return address that you should receive from us first. Please ship the order in original packaging with all the accessories and additional parts. If the Required Parts are not sent back, they will be billed for or expected to be shipped at a later stage. And only once all items have arrived will our staff check the returned product for testing. Include in your package a signed letter stating the reason for your return and the original receipt as well as any mentioned proof of defect, images, or a video, etc. It will help us to speed up the process on your behalf.

The purchaser (customer/buyer) is responsible for all shipping costs when returning an item. However, upon receiving the returned order, we will assess the product. If it is determined that there is, in fact, a manufacturing defect, then we will refund the shipping costs as well as repair or replace or refund the full amount to the purchaser if the product is not fixable.

If you wish to return an unused product, please do so within seven days from the ship date for a refund on the purchase price, minus shipping, handling. Refunds will be credited to the original credit card used for payment in 24-48 HOURS after receiving the product back. We will charge 50% restocking fee.

Once your return is received and inspected, and if agreed for a refund, refunds will be credited to the original credit card used for payment in 24-48 hours. Please note that we will charge a 50% restocking fee once you return a product without any defect.

Once your refund is processed, PayPal will return the money to the card used. It may take at least five business days (depending on the bank and credit company) before your refund is posted in your bank account and statements. Contact Us if you still have not received your refund after 5 business days.

Do not return your product to our New York office. For any exchange or refunds, please email us first at support@ozrobotics.com for us to provide you with the steps that need to be followed. Any product you return must be in the same condition you received and returned in the original packaging without being used. Please keep the original receipt. More on Refund and Replacement Policy.

Shipping costs

Region / Country State Postcode Cost
United States (US) Any Any $25.00
Any Any Any $25.00

The product link will be added to your question automatically upon submission.

    What frequency range is passed to the subwoofer channel
  1. 0 votes
    Q What frequency range is passed to the subwoofer channel
    Asked by Chris
    Answered by Oz Robotics

    Chris, its full frequency passed to the subwoofer channel. You can connect a TSA1701 to the tones set port to change the frequency range. Thank you.

  2. if i ran this at 24v is there any 12v power outputs i can splice into for an accessory device?? ?
  3. 0 votes
    Q if i ran this at 24v is there any 12v power outputs i can splice into for an accessory device?? ?
    Asked by tony
    Answered by Oz Robotics

    Hi Tony, this board without 12V output. Thank you.

  4. Are power ratings rms,peak or peak to peak
  5. 0 votes
    Q Are power ratings rms,peak or peak to peak
    Asked by Philip
  6. Hello, I would like to order this amplifier Board, but it would be possible the audio B Board has SMA antenna conector, and how do I order with this SMA conector
  7. 0 votes
    Q Hello, I would like to order this amplifier Board, but it would be possible the audio B Board ha...... Read more
    Asked by Johnnary D Gonzalez
    Answered by Oz Robotics Hi Johnnary. we can provide the SMA connector version. Just leave a note on the order. We will ship the SMA version.
