OEM Receiver Processor TT-SG1 with ADS-B, GNSS
This is a high-quality and low-price OEM ADS-ÂB/GNSS receiver series operating at 1090MHz. It is based on the proven FPGA-In-The_LoopTM technology, a unique combination of a single-core processor and FPGA.
- The patented solution allows high-speed RF data processing with a significantly reduced number of electronic components. The module’s simultaneous miniaturization and OEM nature open various possible applications.
- A fast UART interface and easy configuration with ATÂcommands allow for the module’s simple integration with the user’s system. In addition, extra interfaces allow for customizing the firmware and extending the module with nonÂstandard functions. Several communication interfaces, protocols, and special functionalities are available on request.
Product Status
To provide the highest level of service to our customers, we would like to inform you about the current stage of the Aerobits product life cycle. Below, you will find a definition of the life cycle, and each product on the site is marked at which stage of the life cycle.
Product lifecycle in Aerobits
-
- In development – Product in preparation. Not available for purchase.
- Engineering samples – Product still in development. Small quantities are available for test purposes.
- Active – Product is available for purchase and fully supported. EOS and EOL dates are not defined
- NRND (Not Recommended for New Design) – The product will be discontinued. It will probably be replaced by a better design. EOS and
- EOL dates are defined.
- EOS (End Of Support): The product is no longer maintained, and support is limited. The product can not be purchased via a webpage. To purchase a product, don’t hesitate to contact sales.
- EOL (End of Life) means the product is no longer produced and can only be bought in larger quantities.
Features
-
-
- Fastest ADS-B implementation on a surface of < 4 cm2
- Receiving ADS-B, Mode-A/C/S with RF signal
- RAW HEX, CSV, AERO, MAVLink, ASTERIX, GDL90
- Strength/quality analysis
- Timestamp for multilateralism
- Best-in-class aircraft tracking
- Scalable OEM solution with enormous customization potential
- Firmware update capability
- Weight < 2g
- Designed to meet the MOPS defined in TSO-C199
- Evaluation kit available
-
Applications
-
-
- SAA / DAA (Sense and Avoid / Detect and Avoid)
- UAS ground stations and high-density traffic surveillance
- UTM / U-Space construction (traffic surveillance network)
- Traffic-flow analysis and statistics
- Monitoring of the 1090 MHz band (signal integrity check)
- ADS-B/In/Out devices that meet the NextGen/SESAR philosophy
-
