RC 4WD Robot with Snow Blower

$9,850.00

The power of this robot will allow you to clear your driveway and sidewalk while you stay in the comfort of your home or business.


Manufactured in: United States (US)

Oz Robotics Manufacturer/Partner : SuperDroid Robots
SKU: TP-193-004 Category: Tags: , , , , Brand/Supplier:

RC 4WD Robot with Snow Blower

Please click on the Help tab to contact us with your address for a shipping estimate. The image gallery displays robots built using this platform. This item does not qualify for free shipping.

This is a custom 4-wheel drive remote control snow blower robot. It includes an Ariens compact 24″ Snow Blower and uses our powerful Wheelchair Motors. The power of this robot will allow you to clear your driveway and sidewalk while you stay in the comfort of your home or business. Check out our video at the bottom of this page for a detailed discussion and demonstration of this custom robot!

Specifications:

Chassis: Custom Aluminum chassis made of 3/16″ thick aluminum. Cut on our CNC Plasma and welded together to house all the components including the mount for the included snow blower
Motors: (Qty 2) DG-158 24VDC 135 RPM Wheel Chair Motors Pair
Lighting: Provided by the Ariens Compact 24 Snow Blower.

Wheels, Shafts and Bearings:

(Qty 4) 13″ inch tiller tires
(Qty 4) Custom steel shafts 1 inch in diameter
Heavy Duty Chain and sprockets coupling motors to the axles with a reduction for greater torque
Heavy duty chain and sprockets coupled axles for greater off-road capability.

(Qty 8) Pillow block 1 inch ball bearings
Batteries: (Qty 4) 12v 35 amp hour batteries wired in series and parallel for 24 volts and 70Ahrs of battery power.
Motor Controller: Sabertooth Dual 60A motor driver
Remote Control: Spektrum DSMX DX7S Transmitter and Spektrum R9020 9-Channel DSMX X-Plus Receiver (Fail Safe)
Snow Blower (Ariens Compact 24inch Snow Blower):
Powerful Ariens AX 208 cc snow engine

Two stage engine:

Remote start / Remote Stop
Tail hitch for pull behind lawn mower, yard cart, fertilizer etc..
24 inch clearing path with 20 inch intake height
205 degree quick turn chute with remote deflector throws snow up to 40 ft

Other accessories:

24 Volt Power Solenoid
24VDC to 115VAC Inverter for powering snow blower inverter
(Qty 2) Battery Chargers
(Qty 2) RC Relay Switches
Linear actuator for engaging the snow blower
(Qty 2) Linear actuators for tilting the snow blower
Gear motor with chain and sprockets for turning the snow blower chute
(Qty 3) Syren 10A Motor Controllers

Dimensions and weight:

Weight: ~400 lbs with the blower (~190 lbs)
Dimensions with snow blower: 26″ Wide X 38″ Tall x 58″ Long. Perfect for driveways and sidewalks! Fits through a standard entry door.
Dimensions: 26″ Wide x 19″ Tall x 36″ Long (does not include the snow blower)

Contact Us if you need this robot customized. We can add additional batteries, cameras, etc. We can even make it Wi-Fi so you can control it over the internet. It can be customized to include any features that you want.

Delivery:

This item is Built to Order and usually ships in 4-8 Weeks.
Due to the size of this item, freight shipping is typically required. We will contact you after checkout with freight costs and arrangements.
Need it faster? Contact us
