Swellpro Fisherman FD1 Fishing Drone FPV Bundle
It uses the same technology as SplashDrone 3+ but removed all the bells and whistles that don’t contribute to bait dropping. With a stronger propulsion system. Fisherman FD1 enables higher bait lit capacity, longer flight time, and better wind resistance than SplashDrone 3+. Fly more baits further out and reel more fish in less hours.
Aircraft
- Waterproof Rating: IP67
- Drone Weight (include battery and propellers)2050g
- Axis Diameter:450 mm
- Max Ascend Speed:4 m/s
- Max Descend Speed:4 m/s
- Max Flight Speed: 10 m/s(GPS); 22 m/s(ATTI)
- Max Tilt Angle: ATTI Fast Mode 25°;ATTI Slow Mode 12.5°
- Max Altitude from Takeoff Point: 120 m (GPS) / 1.3 km (ATTI)
- Max Wind Speed Resistance: 72km/h | 20 m/s | 39knot
- Hovering Accuracy:±0.5m
- Max Flight Time: 30 mins (no wind & no load); (approx. 15 mins with 1.0kg, approx.12 mins with load of 1.5kg)
- Max Flight Distance: 1.6 km
- Max Payload Capacity:2.0 kg
- Satellite Positioning Systems: GPS/GLONASS
- Flight Control: Hawk
- Motor: #3509/740Kv
- ESC: 40A (flux)
- Propeller:#1242 carbon fiber quick-release propellers
- Working Temperature: -10℃ ~ 40℃
- Battery Type: 4S 15.2V 6500mAh Lipo
- Battery Weight: 640g
- Charging Time: 90 min
Remote Control
- Weight:378 g (without battery)
- Size:174x89x190 mm
- Frequency:2405 – 2475 MHz
- Band Wide: 5000 kHz
- Coding Mode: GFSK
- Effective Distance: 1.3 km (No interference, open area)
- Receiving Sensitivity: -105dBm
- Transmitting Power: Less than 20dBm
- Channel:6
- Battery Type: 6V (1.5V AAx4)
PL1-F
- Waterproof: IP67
- Max Payload Weight: 2kg
- Size:60.7*36.2*50mm
- Cable Length: 220mm
- Weight:90g
PL2-F
- Waterproof: IP67
- Max Payload Weight: 2kg
- Size: 122.5*50*39mm
- Cable Length:160mm
- Weight:150g
- Sensor Size: 1/2.7; support WDR (Wide Dynamic Range)
- Resolution: 2000TVL | 800×480
- Lens: F/2.5 f/2.1
- Input Voltage: 5~36V
Video Link
- Frequency: 5645 ~ 5965MHz
- Channel: 40CH
- Transmission Distance: 1.6km (No obstacles, no interference)
- Power: 25mW
- Input Voltage: 7.4~26V
- Size: 32*25*10.4mm(天线140mm)
- Weight: 12.8g
Dual Usage FPV screen and goggle – GL1
- Screen Size: 5″
- Resolution: 800 * 480
- Display Scale:16:9
- Brightness: 300cd /m²
- Latency: <20ms
- Lens: 8 times Fresnel lens, light transmittance 92%, no distortion of light
Antenna:2 X RP-SMA male
- USB: For charging(max charging current: 500mA)
- Card Slot: Micro SD card (64G max)
- Recording Resolution: VGA / D1 / HD optional
- REC sound: ON / OFF
- Recording Section: OFF / 3min / 5min / 10min
- Resolution: 30FPS
- Compress Format: MJPEG
- Video Format: AVI
- Language: EN/CN
- Power: DC5V / 2A(USB)
- Battery: Built-in 3.7V / 2000mAh Lipo Battery
- DVR ON – 2.5hour | DVR OFF – 3.5hour”
- Size: 180mm * 140mm * 84mm
- Weight: 393g
