Swellpro Fisherman FD1 Fishing Drone FPV Bundle


Fisherman FD1 enables higher bait lit capacity, longer flight time, and better wind resistance than SplashDrone 3+. As a result, fly more baits out and reel more fish in fewer hours.

Made In: China

Brand: Swellpro SKU: FD1+PL2-S+VTX+BP1 Categories: , Tags: , , , , More From:

Swellpro Fisherman FD1 Fishing Drone FPV Bundle

It uses the same technology as SplashDrone 3+ but removed all the bells and whistles that don’t contribute to bait dropping. With a stronger propulsion system. Fisherman FD1 enables higher bait lit capacity, longer flight time, and better wind resistance than SplashDrone 3+. Fly more baits further out and reel more fish in less hours.


  • Waterproof Rating: IP67
  • Drone Weight (include battery and propellers)2050g
  • Axis Diameter:450 mm
  • Max Ascend Speed:4 m/s
  • Max Descend Speed:4 m/s
  • Max Flight Speed: 10 m/s(GPS); 22 m/s(ATTI)
  • Max Tilt Angle: ATTI Fast Mode 25°;ATTI Slow Mode 12.5°
  • Max Altitude from Takeoff Point: 120 m (GPS) / 1.3 km (ATTI)
  • Max Wind Speed Resistance: 72km/h | 20 m/s | 39knot
  • Hovering Accuracy:±0.5m
  • Max Flight Time: 30 mins (no wind & no load); (approx. 15 mins with 1.0kg, approx.12 mins with load of 1.5kg)
  • Max Flight Distance: 1.6 km
  • Max Payload Capacity:2.0 kg
  • Satellite Positioning Systems: GPS/GLONASS
  • Flight Control: Hawk
  • Motor: #3509/740Kv
  • ESC: 40A (flux)
  • Propeller:#1242 carbon fiber quick-release propellers
  • Working Temperature: -10℃ ~ 40℃
  • Battery Type: 4S 15.2V 6500mAh Lipo
  • Battery Weight: 640g
  • Charging Time: 90 min

Remote Control

  • Weight:378 g (without battery)
  • Size:174x89x190 mm
  • Frequency:2405 – 2475 MHz
  • Band Wide: 5000 kHz
  • Coding Mode: GFSK
  • Effective Distance: 1.3 km (No interference, open area)
  • Receiving Sensitivity: -105dBm
  • Transmitting Power: Less than 20dBm
  • Channel:6
  • Battery Type: 6V (1.5V AAx4)


  • Waterproof: IP67
  • Max Payload Weight: 2kg
  • Size:60.7*36.2*50mm
  • Cable Length: 220mm
  • Weight:90g


  • Waterproof: IP67
  • Max Payload Weight: 2kg
  • Size: 122.5*50*39mm
  • Cable Length:160mm
  • Weight:150g
  • Sensor Size: 1/2.7; support WDR (Wide Dynamic Range)
  • Resolution: 2000TVL | 800×480
  • Lens: F/2.5 f/2.1
  • Input Voltage: 5~36V

Video Link

  • Frequency: 5645 ~ 5965MHz
  • Channel: 40CH
  • Transmission Distance: 1.6km (No obstacles, no interference)
  • Power: 25mW
  • Input Voltage: 7.4~26V
  • Size: 32*25*10.4mm(天线140mm)
  • Weight: 12.8g

Dual Usage FPV screen and goggle – GL1

  • Screen Size: 5″
  • Resolution: 800 * 480
  • Display Scale:16:9
  • Brightness: 300cd /m²
  • Latency: <20ms
  • Lens: 8 times Fresnel lens, light transmittance 92%, no distortion of light

Antenna:2 X RP-SMA male

  • USB: For charging(max charging current: 500mA)
  • Card Slot: Micro SD card (64G max)
  • Recording Resolution: VGA / D1 / HD optional
  • REC sound: ON / OFF
  • Recording Section: OFF / 3min / 5min / 10min
  • Resolution: 30FPS
  • Compress Format: MJPEG
  • Video Format: AVI
  • Language: EN/CN
  • Power: DC5V / 2A(USB)
  • Battery: Built-in 3.7V / 2000mAh Lipo Battery
  • DVR ON – 2.5hour | DVR OFF – 3.5hour”
  • Size: 180mm * 140mm * 84mm
  • Weight: 393g
