17 DoFs Robotic Grasping 5 Fingers Human-Like Humanoid Dexterous Hand

17 DoFs Robotic Grasping 5 Fingers Human-Like Humanoid Dexterous Hand

Original price was: $2,678.00.Current price is: $2,263.00.

Robotic Grasping 5 Fingers Human-Like Humanoid Dexterous Hand


Ships From: China
Brand: Honpine SKU: HONPINE 07 Categories: , Tags: , , , ,

17 DoFs Robotic Grasping 5 Fingers Human-Like Humanoid Dexterous Hand

HONPINE 07 robot hand is a high-performance dexterous hand with 17 DoFs. Powered by self-developed motors, it balances cost control with reliable grasping and operation performance, meeting diverse application needs. It provides ROS plugins for secondary development, suitable for education & research, auxiliary grasping, and intelligent interaction, offering an efficient, economical, and dexterous hand solution for robotic systems.

Features

  • Human-Like Configuration & Multi-DoF
  • Highly mimics human hand structure, enabling precise simulation of grasping and operational postures to adapt to complex task scenarios.
  • Self-Locking & High-Torque Transmission
  • Self-developed worm gear drive system delivers strong high-torque output and self-locking function, ensuring precise control and power-off

Robot Hand Interfaces

  • Supported robotic arms: UR, Franka, XArm, RealMan, Songling
  • Supported data acquisition methods: teleoperation gloves, exoskeleton gloves, liquid metal gloves, vision, VR (Meta Quest 3)
  • Supported simulators: PyBullet, Isaac, MuJoCo
  • Supported interfaces: CAN, 485
  • Example usage: ROS1, ROS2, Python, C++

Specifcations

Degrees of Freedom 7
Number of Joints 17 (7 active + 10 passive)
Transmission Type Worm gear drive
Control Interface CAN/RS-485
Weight 634.5g
Maximum Load 25kg
Operating Voltage DC24V±10%
Static Current 0.2A
Average No-load Operating Current 0.7A
Maximum Current 2.6A
Repeat Positioning Accuracy <±0.2mm
Opening/Closing Time 1.25s
Maximum Thumb Tip Force 14N
Maximum Four-Finger Tip Force 14N
Maximum Five-Finger Gripping Force 60N
