M.2 Wireless Module A8 for ROCK 3A, ROCK 5B, WiFi

$26.99

The M.2 A8 wireless module supports WiFi 6 and Bluetooth 5.2 and is compatible with ROCK 3A and ROCK 5B.


Ships From: United Kingdom (UK)

Supplier: SB Components SKU: SKU26845 Categories: , , Tags: , , , , , , ,

M.2 Wireless Module A8 for ROCK 3A, ROCK 5B, WiFi

This M.2 wireless module, based on the Realtek RTL8852BE chip and compatible with ROCK 3A and ROCK 5B boards, is a WiFi 6 and BT5.2 combination module that improves the wireless and Bluetooth connectivity of your board.

  • M.2 Wireless Module A8 for ROCK 3A, ROCK 5B, WiFi 6, BT5.2
  • M.2 Wireless Module
  • Compatible with ROCK 3A and ROCK 5B single-board computers (SBC)
  • Enhances your ROCK board’s wireless and Bluetooth connectivity
  • WiFi 6
  • BT5.2

enter image description here

Rock M.2 Wireless Module A8 Features:

  • IEEE 802.11a/b/g/n/ac/ax compatible WLAN
  • DBBT5.0 (BT 5.2 Compliant)
  • Complete 802.11n MIMO solution for 2.4GHz and 5Ghz band
  • Maximum PHY data rate up to
  • 286.8 Mbps using 20MHz bandwidth
  • 573.5Mbps using 40MHz bandwidth
  • 1201Mbps using 80MHz bandwidth
  • Backward compatible with 802.11a/b/g devices while operating at 802.11n data rates
  • Backward compatible with 802.11a/n/ac devices while operating at 802.11ax data rates
  • Compliance with Windows operating system host implemented FIPS 140 2 security requirements
  • Support 20/40/80MHz 5GHz
  • supports WLAN Bluetooth coexistence
  • supports low-power Bluetooth
  • Support Bluetooth five system (BT 5.2 Logo Compliant)
  • Compatible with Bluetooth v2.1+EDR
  • 2x uFL connector

Kit Content: 1 x M.2 Wireless Module Only
