OEM Processor Receiver Antenna with ADS-B, Mode A, C, and S Timestamp TT-SC1-EXT
OEM ADS-B receiver TT-SC1-EXT
- TT-SC1-EXT is a high-quality, low-priced OEM ADS-B receiver series operating at 1090 MHz.
- The patented FPGA-In-The_LoopTM technology allows high-speed RF data processing with a significantly reduced number of electronic components.
- Simultaneous miniaturization of the module and its OEM nature opens various possible applications.
Two versions are available.
- Version a – antenna input on pin
- Version b – antenna input to UFL connector
Product Status: Active – Product lifecycle: Information for customers
To provide the highest level of service to our customers, we would like to inform you about the existing stage of the Aerobits product life cycle. Below, you will find a definition describing the life cycle, and each product on the site is marked at which stage of the product’s life cycle.
Product lifecycle in Aerobits
- In development – Product in preparation. Not available for purchase.
- Engineering samples – Product still in development. Small quantities are available for test purposes.
- Active – The product is available for purchase and fully supported. EOS and EOL dates are not defined
- NRND (Not Recommended for New Design) – The product will be discontinued. It will probably be replaced by a better design. EOS and
- EOL dates are defined.
- EOS (End Of Support): The product is no longer maintained, support is limited, and it can not be purchased through a webpage. To purchase a product, don’t hesitate to contact sales.
- EOL (End of Life) means the product is no longer produced and can only be bought in larger quantities.
Features
- Smallest ADS-B implementation on a surface of <2Â cm2
- Receiving Mode A/C/S with RF signal strength/quality analysis
- Timestamp (raw data only) for multilateralism
- High-Âresolution ADC with real-Âtime signal processing; best-Âin-Âclass aircraft tracking
- High sensitive front-Âend, jamming and ESD protection (only TT-ÂSC1b) with ranges over 150 km (open space, 1dBi antenna)
- Simple module integration and configuration via the UART interface and AT commands
- RAW HEX, CSV, AERO, MAVLink, ASTERIX, GDL90
- Scalable OEM solution with enormous customization potential (additional functions or interfaces on request)
- Firmware update capability (uC and FPGA)
- Low power consumption 3.3V/70mA
- Small outline: 16.0 x 13.0 x 2.65mm, ver. (a); 20 x 13.0 x 2.65mm, ver. (b), weight < 1.5g
- Designed to meet the MOPS defined in TSO-C199
- Evaluation kit available.
Applications
- SAA / DAA (Sense and Avoid / Detect and Avoid)
- UAS collision avoidance systems
- UTM / U-Space traffic awareness devices
- Early warning devices for UAS operators
- Collision prediction devices for gliders/paragliders
- ADS-B In devices that meet the NextGen/SESAR philosophy
