AiryFi Air Quality Monitor Device Based on ESP8266

$94.99

AiryFi is an air Quality Monitor Device Based on the ESP8266 WiFi Microchip PMSA003 Sensor Air Monitor Breakout with an inbuilt 1.14″ TFT Display.

AiryFi Air Quality Monitor Device Based on ESP8266

AiryFi is a portable open-source sensor that can measure the number and mass of dispersed particles. It features a PMSA003 sensor that provides information on suspended particulate matter (PM1.0, PM2.5, and PM10) in the air per unit volume through a digital output with a 5V operating voltage. In addition, it includes an on-board 1.14” TFT LCD, ESP8266-12E, USB C port for charging and communication, CP2102, Battery Connector, On/Off switch, Flash, PMSA003 sensor selection jumper, and BME280 sensor.

Features:

  • Digital humidity, pressure, and temperature sensor
  • Digital and universal particle concentration sensor
  • Zero false alarm rate with Real-time response
  • Minimum distinguishable particle diameter: 0.3 micrometer
  • High anti-interference performance because of the patent structure of six-side shielding
  • Wi-Fi 2.4 GHz, support WPA/WPA2
  • Support STA/AP/STA+AP operation modes
  • Support Smart Link Function for both Android and iOS devices
  • Operating temperature range -40C ~ 125C

Kit Content:

  • 1 x AiryFi
  • 1 x AiryFi Enclosure
