Nema 17 External 34mm Stack 0.4A Lead 8mm/0.31496″ Length 32mm

$38.58

This model is an economy linear stepper motor named Nema 17 external linear actuator, and the motor part is 34mm 1.8 degrees 0.4A Nema 17 stepper motor. It was integrated with a 32mm Tr8x8 threaded rod, and a Brass screw nut moved along the threaded rod.

In stock


Made In: China

Supplier: StepperOnline SKU: 17LS13-0404E-32G Categories: , Tags: , , , , , ,

Nema 17 External 34mm Stack 0.4A Lead 8mm/0.31496″ Length 32mm

This model is an economy linear stepper motor named Nema 17 external linear actuator, and the motor part is 34mm 1.8 degrees 0.4A Nema 17 stepper motor. It was integrated with a 32mm Tr8x8 threaded rod, and a Brass screw nut moved along the threaded rod.

Electrical Specifications

Manufacturer Part Number: 17LS13-0404E-32G
Motor Type: External Linear Stepper
Step Angle: 1.8 deg
Holding Torque: 26Ncm(36.8oz.in)
Rated Current/phase: 0.4A
Phase Resistance: 30ohms
Voltage: 12V
Inductance: 37mH ± 20%(1KHz)
Physical Specification
Frame Size: 42 x 42mm
Body Length: 34mm
Lead Screw Length: 32mm(1.2598″)
Lead Screw Diameter: Φ8mm(0.315″)
Lead /Step: 0.04mm(0.0015748″ )
Lead/Revolution: 8mm(0.315″)
Number of Leads: 4
Lead Length: 400mm
Weight: 400g
