Planetary Actuator DC Motor RMD-X4-36 Crossed Roller Bearing Robot Motion Control EtherCAT High-Speed

$400.00

Planetary Actuator DC Motor RMD-X4-P36-36-E Designed for high-dynamic, high-precision, high-reliability scenarios; it is an ideal choice for humanoid robot joint drive, bionic leg drive: anti-bending moment design + instantaneous torque response to achieve smooth switching of complex gaits such as running and jumping

EtherCAT+CAN dual protocol, 250μs ultra-fast response

  • Gear Ratio: 36
  • Input Voltage: 24v
  • No Load Speed: 111RPM
  • No-Load input Current: 0.9A
  • Rated Speed: 83RPM
  • Rated Torque: 11.5N.M
  • Rated Output Power: 100W
  • Peak Torque: 34N.M

MyActuator   RMD-X4-P36-36-E  The large hollow structure is compatible with multi-sensor integration, providing a data center for the robot’s full-body posture control EtherCAT high-speed communication supports multi-machine linkage, meeting the needs of efficient collaboration in flexible production lines.
