M1200 is the preferred platform for a 2-5kg payload. It focuses on customers who need heavier payloads. The 1h+ flight time improves work efficiency and user experience.
- Quadcopter
- Foldable
- Long endurance
- Heavy payloads
Benefits and Features
- Lightweight Design: Hollow Design: Extrusion forming of the integrated body with high-strength aviation aluminum for greater strength, lighter weight, and smaller volume.
- Long Endurance: It has a one-hour flight time and a 5kg payload. With a 30km data transmission system, it overcomes the distance barrier.
- Customized T-MOTOR Propulsion System: A leader in security, a trusted choice. Given the long endurance characteristics, we get the critical optimization on efficiency, reliability, and weight for longer flight time, stability, and safety.
Optional Payloads
The M1200 has a flexible connector gimbal sharing device and several additional power supply interfaces to achieve multiple purposes. You may choose the following equipment: Thermal Camera, Laser Night Vision, Searchlight, Winch System, and Cargo Box.
| TECHNICAL PARAMETERS | |
|---|---|
| Model | M1200 |
| Wheelbase | 1230mm |
| Weight of Drone (Without Battery) | 5.14kg |
| Weight of Drone (With Battery) | 13.5kg |
| Weight of Battery | 8.36kg(ARES 6S 22AH Battery* 4PCS) |
| Max Take-off Weight | 18.5kg |
| Maximum Ascent Speed | 5m/s |
| Maximum Descending Speed | 3m/s |
| Maximum Horizontal Flight Speed | 15m/s |
| GPS Hover Accuracy | Vertical: ±0.5m; Horizontal: ±2.5m |
| Hover Time | 2kg≥70mins 5kg≥60mins |
| Maximum Tolerable Wind Speed | 13m/s |
| Working Temperature | -15℃~50℃ |
| Propulsion System | T-MOTOR |
| Control System | PIXHAWK |
| Dimensions Folded | 585mm*585mm*570mm |
| Dimensions (Unfolded) | 990mm*1005mm*570mm |
| Packing Size | 700mm*700mm*370mm |
| Shipping Weight | 11.6kg |
M1200 Overview
M1200 is the preferred platform for a 2-5kg payload. M1200 focuses on customers who need larger payloads. 1h+flight time improves work efficiency and user experience.
Benefits and Features
- Lightweight Design: Hollow Design, Extrusion forming of the integrated body with high-strength aviation aluminum for higher strength, lighter weight, and smaller volume.
- Long Endurance: 1h flight time and 5kg payload. With a 30km data transmission system, it overcomes the distance barrier.
- Customized T-MOTOR Propulsion System: A leader in security, a trusted choice.
Given the long endurance characteristics, we get the critical optimization on efficiency, reliability, and weight for longer flight time, stability, and safety.
- Optional Payloads: The M1200 has a flexible connector gimbal sharing device and several additional power supply interfaces to achieve multiple purposes.
- You may choose the following equipment: Thermal Camera, Laser Night Vision, Searchlight, Winch System, and Cargo Box.
- Secondary Development: The M1200 is equipped with a robust secondary development capability, considering customers’ different needs.
- Protection Enhanced: Key areas are closed to improve protection and meet environmental requirements.
- Diverse Choices of Landing Gears: The customer can select from three types of landing gear: fulcrum point, folding, and T-type.
- Different Props: Folding and quick-detachable props for time-saving operation.
- Signal Enhanced: Multiple GPS can be installed for better anti-interference.
Note: The flight controller, Radio with receiver, and battery are not included. You need to purchase them separately.
Battery: Please buy this battery X 4PCS for T-DRONES M1200 Quadcopter: Ares High-Performance New Solid Li-ion 6S 22ah Battery – Oz Robotics
