CSR8670 Bluetooth 5.1 Stereo Audio Transceiver Module Supporting Apt-X FSC-BT806A

$16.99

FSC-BT806A is a CSR8670 High-End Bluetooth Audio Module with Bluetooth 5.1 dual-mode specifications. It adopts the CSR8670 chipset, and supports apt-X,apt-X LL, and CVC features; customers could also set the module parameters via AT commands.

Certification: BQB, FCC, IC, CE, TELEC, KC

CSR8670 Bluetooth 5.1 Stereo Audio Transceiver Module Supporting Apt-X FSC-BT806A

FSC-BT806A is a CSR8670 High-End Bluetooth Audio Module with Bluetooth 5.1 dual-mode specifications. It adopts the CSR8670 chipset and supports apt-X,apt-X LL, and CVC features, and customers could also set the module parameters via AT commands.

FSC-BT806A supports A2DP, AVRCP, HFP, HSP, PBAP, SPP, and GATT profiles; it has an onboard antenna(Default version) and also supports an external antenna(Optional).

Support communicating with the FeasyBlue app and many other Bluetooth apps

Basic Parameter

Bluetooth Module Model FSC-BT806A
Bluetooth version Bluetooth 5.1 dual mode(BR/EDR+BLE)
Chipset CSR8670
Dimension 13mm x 26.9mm x 2.2mm
Transmit power +10dBm
Profiles A2DP, AVRCP, HFP, HSP, PBAP, SPP, GATT
Certification BQB、FCC、IC、CE、TELEC、KC
Frequency 2.402 – 2.480 GHz
Antenna Built-in PCB Antenna(Default), supports external antenna(Optional)
Features Apt-X, apt-X LL, CVC, High-quality audio transceiver

Main Features

● Chipset: CSR8670
● Bluetooth 5.1 dual-mode specifications
● Mini Size : 13*26.9*2.2mm ,Coverage up to 50m(164ft)
● Max Transmit Power: +10 dBm; Receive Sensitivity: -88 dBm
● Audio Interfaces: Dual I2S Output/Input Audio Features, SBC and AAC Audio codec
● Support HFP, HSP, A2DP, PBAP, AVRCP, MAP, SPP, BLE profiles
